SCHMIDT AXXIOM STYLE 3 CUFT PORTABLE BLASTER DELUXE BLASTING PACKAGE PNU REMOTE

SCHMIDT AXXIOM STYLE 3 CUFT PORTABLE BLASTER DELUXE BLASTING PACKAGE PNU REMOTE

  • 4,61700
  • Save $ 71000


Description

ABRASIVE BLAST POT / SANDBLASTING MACHINE, PORTABLE, 3.5 CU. FT. (100 LITERS), 150 PSI (10.3 BAR), PRESSURE RELEASE SYSTEM, PNEUMATIC, INCL: MPV/COMBINATION VALVE, 1" PIPING W/MOISTURE SEPARATOR, 55' TWINLINE ASSY, CONTROL HANDLE #2 & DELUXE BLASTING PACKAGE

• Low profile makes loading of abrasive easy
• Extremely low pressure drop for increased productivity
• 90o angled cone bottom improves abrasive flow
• 150 psi (10.3 bar) rated
• VBS (Volumetric Blowdown Suppression) System
• Reduces blowdown intensity by diffusing and safely re-directing blowdown exhaust air
• No screen or filters to clog = minimal maintenance
• Easy to replace wear components

DELUXE BLASTING PACKAGE INCLUDES THE FOLLOWING

(1) 10-100BLK-050-3AL, 1" BLAST HOSE ASSEMBLY KIT W/COUPLINGS (50')
(1) 1201-1173, #4 TUNGSTEN CARBIDE, ALL POLY NOZZLE
(1) 122-9150, BLAST SUIT, LIGHTWEIGHT, LARGE
(1) 407701, LUXURY DOUBLE PALMED GLOVES (PAIR)
(1) 407000-PFC, NOVA 2000* RESPIRATOR PACKAGE
(1) 10-034RED-050-1, 3/4" AIR HOSE ASSEMBLY KIT (50')
(1) 10-100RED-050-1, 1" AIR HOSE ASSEMBLY KIT (50')
(1) UM-100, AIR HOSE COUPLING, 2 LUG, 1" MALE NPT

FEATURES & BENEFITS OF SPR PNEUMATIC

A. 3.5 CU. FT. CAPACITY (100 LITERS)
     1. 150 PSI VESSEL (10.3 BAR)
     2. A.S.M.E. SECTION VIII DIVISION 1
     3. CRN FOR ALL PROVINCES
B. PRESSURE RELEASE SYSTEM
     1. AUTOMATICALLY BLOWS DOWN THE VESSEL WHEN CONTROL HANDLE IS RELEASED
     2. LOW MAINTENANCE DESIGN
     3. SIMPLE TROUBLE SHOOTING FOR IN FIELD REPAIRS
C. HEAVY DUTY MOISTURE SEPARATOR
D. 1" GALVANIZED PIPING FOR CORROSION RESISTANCE
E. HEAVY DUTY FULL PORT BALL VALVES
F. EXTENDED LIFE SCHEDULE 80 HEAVY DUTY NIPPLE
     1. WITHSTANDS ABRASIVE WEAR FOR LONGER LIFE
H. BOLT CLAMPS ON PUSHER LINE MAKE FIELD REPAIRS EASIER
I. COMBINATION VALVE/MPV VALVE
     1. COMBINATION VALVE IS A 2 IN 1 DESIGN THAT WILL STOP THE AIR BLASTING AND RELIEVES THE PRESSURE FROM THE VESSEL WHEN THE CONTROL HANDLE IS RELEASED
     2. MANUAL PLUNGER VALVE (MPV) IS A SIMPLE RELIABLE DESIGN THAT PROVIDES A WIDE RANGE OF ADJUSTMENT OF ABRASIVE FLOW TO THE NOZZLE
     3. RELIEVING CONTROL HANDLE REDUCES AIR CONSUMPTION AND REDUCES STOPPING TIMES WHEN CONTROL HANDLE IS RELEASED
J. MADE IN USA
